搭建 Postfix 邮箱服务器并实现 ExtMail 的 Web 访问

[root@localhost ~]# setenforce 0
[root@localhost ~]# getenforce

[root@localhost ~]# systemctl stop firewalld
[root@localhost ~]# iptables -F
[root@localhost ~]# iptables -X
[root@localhost ~]# iptables -nvL

yum install -y wget
wget http://dev.mysql.com/get/mysql-community-release-el7-5.noarch.rpm
rpm -ivh mysql-community-release-el7-5.noarch.rpm
wget http://dl.fedoraproject.org/pub/epel/epel-release-latest-7.noarch.rpm
rpm -ivh epel-release-latest-7.noarch.rpm

yum install nginx vim gcc gcc-c++ openssl openssl-devel db4-devel ntpdate mysql mysql-devel mysql-server bzip2 php-mysql cyrus-sasl-md5 perl-GD perl-DBD-MySQL perl-GD perl-CPAN perl-CGI perl-CGI-Session cyrus-sasl-lib cyrus-sasl-plain cyrus-sasl cyrus-sasl-devel libtool-ltdl-devel telnet mail libicu-devel -y

yum remove postfix -y
userdel postfix
groupdel postdrop
groupadd -g 2525 postfix
useradd -g postfix -u 2525 -s /sbin/nologin -M postfix
groupadd -g 2526 postdrop
useradd -g postdrop -u 2526 -s /sbin/nologin -M postdrop

cd /usr/local/src/
wget http://cdn.postfix.johnriley.me/mirrors/postfix-release/official/postfix-3.0.11.tar.gz
tar -zxvf postfix-3.0.11.tar.gz
cd postfix-3.0.11
make makefiles 'CCARGS=-DHAS_MYSQL -I/usr/include/mysql -DUSE_SASL_AUTH -DUSE_CYRUS_SASL -I/usr/include/sasl -DUSE_TLS ' 'AUXLIBS=-L/usr/lib64/mysql -lmysqlclient -lz -lrt -lm -L/usr/lib64/sasl2 -lsasl2 -lssl -lcrypto'
make && make install
echo $?

Please specify the prefix for installed file names. Specify this ONLY if you are building ready-to-install packages for distribution to OTHER machines. See PACKAGE_README for instructions.
install_root: [/]

Please specify a directory for scratch files while installing Postfix. You
must have write permission in this directory.
tempdir: [/usr/local/src/postfix-3.0.11] /tmp/extmail
//就只更改这一项为tmp目录，其他的全部默认

Please specify the final destination directory for installed Postfix configuration files.
config_directory: [/etc/postfix]

Please specify the final destination directory for installed Postfix administrative commands. This directory should be in the command search path of adminstrative users.
command_directory: [/usr/sbin]

Please specify the final destination directory for installed Postfix daemon programs. This directory should not be in the command search path of any users.
daemon_directory: [/usr/libexec/postfix]

Please specify the final destination directory for Postfix-writable data files such as caches or random numbers. This directory should not be shared with non-Postfix software.
data_directory: [/var/lib/postfix]

Please specify the final destination directory for the Postfix HTML files. Specify "no" if you do not want to install these files.
html_directory: [no]

Please specify the owner of the Postfix queue. Specify an account with numerical user ID and group ID values that are not used by any other accounts on the system.
mail_owner: [postfix]

Please specify the final destination pathname for the installed Postfix mailq command. This is the Sendmail-compatible mail queue listing command.
mailq_path: [/usr/bin/mailq]

Please specify the final destination directory for the Postfix on-line manual pages. You can no longer specify "no" here.
manpage_directory: [/usr/local/man]

Please specify the final destination pathname for the installed Postfix newaliases command. This is the Sendmail-compatible command to build alias databases for the Postfix local delivery agent.
newaliases_path: [/usr/bin/newaliases]

Please specify the final destination directory for Postfix queues.
queue_directory: [/var/spool/postfix]

Please specify the final destination directory for the Postfix README files. Specify "no" if you do not want to install these files.
readme_directory: [no]

Please specify the final destination pathname for the installed Postfix sendmail command. This is the Sendmail-compatible mail posting interface.
sendmail_path: [/usr/sbin/sendmail]

Please specify the group for mail submission and for queue management commands. Specify a group name with a numerical group ID that is not shared with other accounts, not even with the Postfix mail_owner account. You can no longer specify "no" here.
setgid_group: [postdrop]

Please specify the final destination directory for Postfix shared-library files.
shlib_directory: [no]

chown -R postfix:postdrop /var/spool/postfix
chown -R postfix:postdrop /var/lib/postfix/
chown root /var/spool/postfix
chown -R root /var/spool/postfix/pid

[root@localhost ~]# vi /etc/postfix/main.cf

myhostname = mail.everyoo.com
//设置主机名
mydomain = everyoo.com
//指定域名
myorigin = $mydomain
//指明发件人所在的域名
inet_interfaces =  all
//all指定postfix系统监听的网络接口
mydestination = $myhostname, localhost.$mydomain, localhost,$mydomain
//指定postfix接收邮件时收件人的域名 [使用虚拟域需要禁用]
mynetworks_style = host
//指定信任网段类型
mynetworks = 192.168.77.1/24, 127.0.0.0/8
//指定信任的客户端
relay_domains = $mydestination
//指定允许中转邮件的域名
alias_maps = hash:/etc/aliases
//设置邮件的别名

[root@localhost /var/www/extsuite/extman]# vi /etc/init.d/postfix

#!/bin/bash
#
# postfix Postfix Mail Transfer Agent
#
# chkconfig: 2345 80 30
# description: Postfix is a Mail Transport Agent, which is the program
# that moves mail from one machine to another.
# processname: master
# pidfile: /var/spool/postfix/pid/master.pid
# config: /etc/postfix/main.cf
# config: /etc/postfix/master.cf
# Source function library.
. /etc/rc.d/init.d/functions
# Source networking configuration.
. /etc/sysconfig/network
# Check that networking is up.
[ $NETWORKING = "no" ] && exit 3
[ -x /usr/sbin/postfix ] || exit 4
[ -d /etc/postfix ] || exit 5
[ -d /var/spool/postfix ] || exit 6
RETVAL=0
prog="postfix"
start() {
     # Start daemons.
     echo -n $"Starting postfix: "
        /usr/bin/newaliases >/dev/null 2>&1
     /usr/sbin/postfix start 2>/dev/null 1>&2 && success || failure $"$prog start"
     RETVAL=$?
     [ $RETVAL -eq 0 ] && touch /var/lock/subsys/postfix
        echo
     return $RETVAL
}
stop() {
  # Stop daemons.
     echo -n $"Shutting down postfix: "
     /usr/sbin/postfix stop 2>/dev/null 1>&2 && success || failure $"$prog stop"
     RETVAL=$?
     [ $RETVAL -eq 0 ] && rm -f /var/lock/subsys/postfix
     echo
     return $RETVAL
}
reload() {
     echo -n $"Reloading postfix: "
     /usr/sbin/postfix reload 2>/dev/null 1>&2 && success || failure $"$prog reload"
     RETVAL=$?
     echo
     return $RETVAL
}
abort() {
     /usr/sbin/postfix abort 2>/dev/null 1>&2 && success || failure $"$prog abort"
     return $?
}
flush() {
     /usr/sbin/postfix flush 2>/dev/null 1>&2 && success || failure $"$prog flush"
     return $?
}
check() {
     /usr/sbin/postfix check 2>/dev/null 1>&2 && success || failure $"$prog check"
     return $?
}
restart() {
     stop
     start
}
# See how we were called.
case "$1" in
  start)
     start
     ;;
  stop)
     stop
     ;;
  restart)
     stop
     start
     ;;
  reload)
     reload
     ;;
  abort)
     abort
     ;;
  flush)
     flush
     ;;
  check)
     check
     ;;
  status)
       status master
     ;;
  condrestart)
     [ -f /var/lock/subsys/postfix ] && restart || :
     ;;
  *)
     echo $"Usage: $0 {start|stop|restart|reload|abort|flush|check|status|condrestart}"
     exit 1
esac
exit $?

[root@localhost /var/www/extsuite/extman]# chmod +x /etc/init.d/postfix
[root@localhost /var/www/extsuite/extman]# chkconfig --add postfix
[root@localhost /var/www/extsuite/extman]# chkconfig postfix on
[root@localhost /var/www/extsuite/extman]# chown postfix.postfix -R /var/lib/postfix/
[root@localhost /var/www/extsuite/extman]# chown postfix.postfix /var/spool/ -R

[root@localhost ~]# yum install -y dovecot dovecot-mysql

[root@localhost ~]# cd /etc/dovecot/
[root@localhost dovecot]# vi dovecot.conf
//直接在配置文件最后添加即可

protocols = imap pop3
!include conf.d/*.conf
listen = *
base_dir = /var/run/dovecot/

[root@localhost dovecot]# cd conf.d/
[root@localhost conf.d]# vi 10-auth.conf

disable_plaintext_auth = no

[root@localhost conf.d]# vi 10-mail.conf

mail_location = maildir:~/Maildir
mail_location = maildir:/var/mailbox/%d/%n/Maildir
mail_privileged_group = mail

[root@localhost conf.d]# vi 10-ssl.conf

ssl = no

[root@localhost conf.d]# vi 10-logging.conf

log_path = /var/log/dovecot.log
info_log_path = /var/log/dovecot.info
log_timestamp = "%Y-%m-%d %H:%M:%S "

[root@localhost conf.d]# cp auth-sql.conf.ext auth-sql.conf
[root@localhost conf.d]# vi auth-sql.conf

passdb {
    driver = sql
    # Path for SQL configuration file, see example-config/dovecot-sql.conf.ext
    args = /etc/dovecot/dovecot-sql.conf.ext
}
userdb {
    driver = sql
    args = /etc/dovecot/dovecot-sql.conf.ext
}

[root@localhost conf.d]# vi /etc/dovecot-mysql.conf

driver = mysql
connect = host=localhost dbname=extmail user=extmail password=extmail
default_pass_scheme = CRYPT
password_query = SELECT username AS user,password AS password FROM mailbox WHERE username = '%u'
user_query = SELECT maildir, uidnumber AS uid, gidnumber AS gid FROM mailbox WHERE username = '%u'

[root@localhost ~]# wget https://sourceforge.net/projects/courier/files/courier-unicode/1.2/courier-unicode-1.2.tar.bz2
[root@localhost ~]# tar jxvf courier-unicode-1.2.tar.bz2
[root@localhost ~]# cd courier-unicode-1.2
[root@localhost courier-unicode-1.2]# ./configure
[root@localhost courier-unicode-1.2]# make && make install

[root@localhost ~]# cd /usr/local/src/
[root@localhost /usr/local/src]# wget https://sourceforge.net/projects/courier/files/authlib/0.66.2/courier-authlib-0.66.2.tar.bz2
[root@localhost /usr/local/src]# tar -jxvf courier-authlib-0.66.2.tar.bz2
[root@localhost /usr/local/src]# cd courier-authlib-0.66.2
[root@localhost /usr/local/src/courier-authlib-0.66.2]# ./configure --prefix=/usr/local/courier-authlib --sysconfdir=/etc --without-authpam --without-authshadow --without-authvchkpw --without-authpgsql --with-authmysql --with-mysql-libs=/usr/lib64/mysql --with-mysql-includes=/usr/include/mysql --with-redhat --with-authmysqlrc=/etc/authmysqlrc --with-authdaemonrc=/etc/authdaemonrc --with-mailuser=postfix
[root@localhost /usr/local/src/courier-authlib-0.66.2]# make && make install

[root@localhost courier-authlib-0.66.2]# chmod 755 /usr/local/courier-authlib/var/spool/authdaemon
[root@localhost courier-authlib-0.66.2]# cp /etc/authdaemonrc.dist /etc/authdaemonrc
[root@localhost courier-authlib-0.66.2]# cp /etc/authmysqlrc.dist /etc/authmysqlrc
[root@localhost courier-authlib-0.66.2]# vi /etc/authdaemonrc
//配置文件里的验证方法比较多，我们这里只使用authmysql

authmodulelist="authmysql"
authmodulelistorig="authmysql"

[root@localhost courier-authlib-0.66.2]# vim /etc/authmysqlrc
//直接添加到配置文件尾部，然后去上面将响应系统默认的注视掉，或者删除即可

MYSQL_SERVER localhost
MYSQL_USERNAME extmail
MYSQL_PASSWORD extmail
MYSQL_SOCKET /var/lib/mysql/mysql.sock
MYSQL_PORT 3306
MYSQL_DATABASE extmail
MYSQL_USER_TABLE mailbox
MYSQL_CRYPT_PWFIELD password
DEFAULT_DOMAIN test.com
MYSQL_UID_FIELD '2525'
MYSQL_GID_FIELD '2525'
MYSQL_LOGIN_FIELD username
MYSQL_HOME_FIELD concat('/var/mailbox/',homedir)
MYSQL_NAME_FIELD name
MYSQL_MAILDIR_FIELD concat('/var/mailbox/',maildir)

[root@localhost courier-authlib-0.66.2]# cp courier-authlib.sysvinit /etc/init.d/courier-authlib
[root@localhost courier-authlib-0.66.2]# chmod +x /etc/init.d/courier-authlib
[root@localhost courier-authlib-0.66.2]# chkconfig --add courier-authlib
[root@localhost courier-authlib-0.66.2]# chkconfig courier-authlib on
[root@localhost courier-authlib-0.66.2]# echo "/usr/local/courier-authlib/lib/courier-authlib" >> /etc/ld.so.conf.d/courier-authlib.conf
[root@localhost courier-authlib-0.66.1]# ldconfig
[root@localhost courier-authlib-0.66.1]# service courier-authlib start
Starting Courier authentication services: authdaemond

[root@localhost ~]# vi /usr/lib64/sasl2/smtpd.conf
//文件不存在，要自己创建

pwcheck_method: authdaemond
log_level: 3
mech_list: PLAIN LOGIN
authdaemond_path:/usr/local/courier-authlib/var/spool/authdaemon/socket

[root@localhost ~]# vi /etc/postfix/main.cf

##postfix支持SMTP##
smtpd_sasl_auth_enable = yes
smtpd_sasl_local_domain = ''
smtpd_recipient_restrictions = permit_mynetworks,permit_sasl_authenticated,reject_unauth_destination
broken_sasl_auth_clients=yes
smtpd_client_restrictions = permit_sasl_authenticated
smtpd_sasl_security_options = noanonymous

##postfix支持虚拟用户##
virtual_mailbox_base = /var/mailbox
virtual_mailbox_maps = mysql:/etc/postfix/mysql_virtual_mailbox_maps.cf
//这里的配置文件需在后面extman里复制过来
virtual_mailbox_domains = mysql:/etc/postfix/mysql_virtual_domains_maps.cf
virtual_alias_domains =
virtual_alias_maps = mysql:/etc/postfix/mysql_virtual_alias_maps.cf
virtual_uid_maps = static:2525
virtual_gid_maps = static:2525
virtual_transport = virtual

[root@localhost ~]# cd /usr/local/src/
[root@localhost /usr/local/src]# wget http://7xivyw.com1.z0.glb.clouddn.com/extmail-1.2.tar.gz
[root@localhost /usr/local/src]# wget http://7xivyw.com1.z0.glb.clouddn.com/extman-1.1.tar.gz

[root@localhost /usr/local/src]# mkdir -p /var/www/extsuite
[root@localhost /usr/local/src]# tar -zxvf extmail-1.2.tar.gz -C /var/www/extsuite/
[root@localhost /usr/local/src]# mv /var/www/extsuite/extmail-1.2/ /var/www/extsuite/extmail

[root@localhost ~]# cd /var/www/extsuite/extmail
[root@localhost extmail]# cp webmail.cf.default webmail.cf
[root@localhost extmail]# vi webmail.cf

SYS_SESS_DIR = /tmp/extmail
SYS_UPLOAD_TMPDIR = /tmp/extmail/upload
SYS_USER_LANG = zh_CN
SYS_MIN_PASS_LEN = 8
SYS_MAILDIR_BASE = /var/mailbox
SYS_MYSQL_USER = extmail
SYS_MYSQL_PASS = extmail
SYS_MYSQL_DB = extmail
SYS_MYSQL_HOST = localhost
SYS_MYSQL_SOCKET = /var/lib/mysql/mysql.sock
SYS_MYSQL_TABLE = mailbox
SYS_MYSQL_ATTR_USERNAME = username
SYS_MYSQL_ATTR_DOMAIN = domain
SYS_MYSQL_ATTR_PASSWD = password
SYS_AUTHLIB_SOCKET = /usr/local/courier-authlib/var/spool/authdaemon/socket

[root@localhost extmail]# mkdir -p /tmp/extmail/upload
[root@localhost extmail]# chown -R postfix.postfix /tmp/extmail/

[root@localhost ~]# cd /usr/local/src/
[root@localhost /usr/local/src]# tar -zxvf extman-1.1.tar.gz -C /var/www/extsuite/
[root@localhost /usr/local/src]# cd /var/www/extsuite/
[root@localhost /var/www/extsuite]# mv extman-1.1/ extman

[root@localhost /var/www/extsuite]# cd extman/
[root@localhost /var/www/extsuite/extman]# cp webman.cf.default webman.cf

[root@localhost /var/www/extsuite/extman]# chown -R postfix.postfix /var/www/extsuite/extman/cgi/
[root@localhost /var/www/extsuite/extman]# chown -R postfix.postfix /var/www/extsuite/extmail/cgi/

[root@localhost /var/www/extsuite/extman]# vi docs/extmail.sql

:% s/TYPE/ENGINE/g

[root@localhost /var/www/extsuite/extman]# !service
service mysqld restart
Redirecting to /bin/systemctl restart mysqld.service
[root@localhost /var/www/extsuite/extman]# mysql -uroot < docs/extmail.sql
[root@localhost /var/www/extsuite/extman]# mysql -uroot < docs/init.sql

[root@localhost /var/www/extsuite/extman]# mysql -uroot

mysql> GRANT ALL ON extmail.* to extmail@'%' identified by 'extmail';
//这里是直接授予全部权限在任意的IP地址上了，实际情况根据需求而定
Query OK, 0 rows affected (0.00 sec)

mysql> FLUSH PRIVILEGES;
Query OK, 0 rows affected (0.00 sec)

[root@localhost ~]# cd /var/www/extsuite/extman/docs/
[root@localhost /var/www/extsuite/extman/docs]# cp mysql_virtual_* /etc/postfix/

[root@localhost /var/www/extsuite/extman/docs]# mkdir /tmp/extman
[root@localhost /var/www/extsuite/extman/docs]# chown -R postfix.postfix /tmp/extman/

[root@localhost /var/www/extsuite/extman]# service postfix start
[root@localhost /var/www/extsuite/extman]# ps aux |grep postfix
[root@localhost /var/www/extsuite/extman]# ss -tnluo | grep :25
[root@localhost /var/www/extsuite/extman]# service dovecot start
[root@localhost /var/www/extsuite/extman]# ps aux |grep dovecot
[root@localhost /var/www/extsuite/extman]# systemctl start saslauthd
[root@localhost /var/www/extsuite/extman]# ps aux |grep saslauthd
[root@localhost /var/www/extsuite/extman]# ps aux |grep courier-authlib

[root@localhost courier-authlib-0.66.2]# /usr/local/courier-authlib/sbin/authtest -s login postmaster@extmail.org extmail

Authentication succeeded.
//显示这个表示成功，测试时使用的是postmaster@extmail.org，因为我们导入的数据库init.sql里面自带了这个。
Authenticated: postmaster@extmail.org (uid 2525, gid 2525)
Home Directory: /var/mailbox/extmail.org/postmaster
//这里需要注意/var/mailbox这个目录现在我们还没有创建，后面web访问的时候如果没有会报错,所以提前创建。
Maildir: /var/mailbox/extmail.org/postmaster/Maildir/
Quota: (none)
Encrypted Password: $1$phz1mRrj$3ok6BjeaoJYWDBsEPZb5C0
Cleartext Password: extmail
Options: (none)

[root@localhost courier-authlib-0.66.2]# mkdir /var/mailbox
[root@localhost courier-authlib-0.66.2]# chown -R postfix.postfix /var/mailbox/

[root@localhost ~]# printf "postmaster@extmail.org" | openssl base64
cG9zdG1hc3RlckBleHRtYWlsLm9yZw==
[root@localhost ~]# printf "extmail" | openssl base64
ZXh0bWFpbA==

[root@localhost ~]# telnet localhost 25

Trying ::1...
telnet: connect to address ::1: Connection refused
Trying 127.0.0.1...
Connected to localhost.
Escape character is '^]'.
220 mail.daen.com ESMTP Postfix
auth login
334 VXNlcm5hbWU6
cG9zdG1hc3RlckBleHRtYWlsLm9yZw==
334 UGFzc3dvcmQ6
ZXh0bWFpbA==
235 2.7.0 Authentication successful   //成功
quit
221 2.0.0 Bye
Connection closed by foreign host.

[root@localhost ~]# vi /var/www/extsuite/extmail/dispatch-init

SU_UID=postfix
SU_GID=postfix

[root@localhost ~]# /var/www/extsuite/extmail/dispatch-init start
[root@localhost ~]# /var/www/extsuite/extman/daemon/cmdserver -v -d

[root@localhost ~]# vi /etc/nginx/conf.d/extmail.conf

server {
   listen 8080;
   server_name mail.everyoo.com;
   index index.html index.htm index.php index.cgi;
   root /var/www/extsuite/extmail/html/;
   location /extmail/cgi/ {
             fastcgi_pass 127.0.0.1:8888;
             fastcgi_index index.cgi;
             fastcgi_param SCRIPT_FILENAME /var/www/extsuite/extmail/cgi/$fastcgi_script_name;
             include fcgi.conf;
        }
        location /extmail/ {
             alias /var/www/extsuite/extmail/html/;
        }
        location /extman/cgi/ {
             fastcgi_pass 127.0.0.1:8888;
             fastcgi_index index.cgi;
             fastcgi_param SCRIPT_FILENAME /var/www/extsuite/extman/cgi/$fastcgi_script_name;
             include fcgi.conf;
        }
        location /extman/ {
             alias /var/www/extsuite/extman/html/;
        }
      access_log /var/log/extmail_access.log;
}

[root@localhost ~]# vi /etc/nginx/fcgi.conf

fastcgi_param GATEWAY_INTERFACE CGI/1.1;
fastcgi_param SERVER_SOFTWARE nginx;
fastcgi_param QUERY_STRING $query_string;
fastcgi_param REQUEST_METHOD $request_method;
fastcgi_param CONTENT_TYPE $content_type;
fastcgi_param CONTENT_LENGTH $content_length;
fastcgi_param SCRIPT_NAME $fastcgi_script_name;
fastcgi_param REQUEST_URI $request_uri;
fastcgi_param DOCUMENT_ROOT $document_root;
fastcgi_param SERVER_PROTOCOL $server_protocol;
fastcgi_param REMOTE_ADDR $remote_addr;
fastcgi_param REMOTE_PORT $remote_port;
fastcgi_param SERVER_ADDR $server_addr;
fastcgi_param SERVER_PORT $server_port;
fastcgi_param SERVER_NAME $server_name;

[root@localhost ~]# cd /usr/local/src/
[root@localhost /usr/local/src]# wget http://www.cpan.org/authors/id/M/MH/MHARNISCH/Unix-Syslog-1.1.tar.gz
[root@localhost /usr/local/src]# tar zxvf Unix-Syslog-1.1.tar.gz
[root@localhost /usr/local/src]# cd Unix-Syslog-1.1
[root@localhost /usr/local/src/Unix-Syslog-1.1]# perl Makefile.PL
[root@localhost /usr/local/src/Unix-Syslog-1.1]# make && make install

[root@localhost ~]# service nginx start
[root@localhost ~]# ps aux |grep nginx
[root@localhost ~]# netstat -lntp
